Moxa nport 5630-16 rs -422/485 Rackmount endistriyèl sèvè aparèy seri
Inrodiksyon
Moxa nport 5630-16 serveurs aparèy yo fèt yo fè aparèy seri rezo-pare nan yon moman. Gwosè a ti nan serveurs yo fè yo ideyal pou konekte aparèy tankou lektè kat ak terminaux peman nan yon IP ki baze sou Ethernet LAN. Sèvi ak serveurs aparèy MOXA 5630-16 pou bay lojisyèl PC ou aksè dirèk nan aparèy seri soti nan nenpòt kote sou rezo a.
Karakteristik ak benefis yo
- Estanda 19- pous gwosè rackmount.
- Fasil adrès IP anviwònman ak panèl la LCD (eksepte lajè-tanperati varyant).
- Configured via Telnet, navigatè entènèt, oswa Windows sèvis piblik.
- Mòd priz: SNMP MIB-II yo itilize pou administrasyon rezo a epi li gen ladan TCP sèvè, TCP kliyan, ak pwotokòl UDP.
- Inivèsèl High-Voltage Ranje: 100 a 240 VAC (88 a 300 VDC)
- Popilè ki ba-vòltaj chenn: ± 48 VDC (20-72 Vdc, -20-72 VDC).
Espesifikasyon
Koòdone Ethernet
|
10/100baset (x) pò (RJ45 Connector) |
1 |
|
Pwoteksyon izolasyon mayetik
|
1.5 kV (bati-an) |
Karakteristik lojisyèl Ethernet
|
Opsyon konfigirasyon |
Telnet Console, Web Console (HTTP/https), Windows sèvis piblik |
|
Jesyon |
ARP, BOOTP, DHCP Kliyan, DNS, HTTP, HTTPS, ICMP, IPV4, LLDP, RFC2217, RTELNET, PPP, SLIP, SMTP, SNMPV1/V2C, TCP/IP, TELNET, UDP |
|
Filtre |
Igmpv1/v2c |
|
Windows Imobilye Com Chofè
|
Windows 95/98/ME/NT/2000, Windows XP/2003/Vista/2008/7/8/8.1/10 (x 86/x64), Windows 2 0 0 8 R2/2012/22 R2/2016/2019 (x64), Windows Embedded CE 5.0/6.0, Windows XP entegre |
|
Linux reyèl chofè tty |
Vèsyon Kernel: 2.4.x, 2.6.x, 3.x, 4.x, ak 5.x |
|
Chofè tty fiks yo |
SCO UNIX, SCO OpenServer, Unixware 7, QNX 4.25, QNX 6, Solaris 10, FreeBSD, AIX 5. X, HP-UX11I, Mac OS X, MacOS 10.12, MacOS 10.13, MacOS 10.14, MacOS 10.15 |
|
Android API |
Android 3.1.x epi pita |
|
Jesyon tan |
SNTP |
Paramèt pouvwa
|
Antre aktyèl |
Nport 5610-8-48 V/16-48 V: 135 Ma @ 48 VDC Nport 5650-8- hv-t/16- hv-t: 152 ma @ 88 VDC Nport 5610-8/16: 141 Ma @ 100Vac Nport 5630-8/16: 152mA @ 100 VAC Nport 5650-8/8- T/16/16- T: 158 Ma @ 100 VAC Nport 5650-8- m-sc/16- M-sc: 174 Ma@100 VAC Nport 5650-8- s-sc/16- s-sc: 164 mA@100 VAC |
|
Antre vòltaj |
HV Modèl: 88 a 300 VDC Modèl AC: 100 a 240 VAC, 47 a 63 Hz DC Modèl: ± 48 VDC, 20 a 72 VDC, -20 Pou -72 VDC |
Karakteristik fizik
|
Lojman |
Metal |
|
Enstalasyon |
19- pous etajè monte |
|
Dimansyon (ak zòrèy) |
480 x 45 x 198 mm (18.90 x 1.77 x 7.80 nan) |
|
Dimansyon (san zòrèy) |
440 x 45 x 198 mm (17.32 x 1.77 x 7.80 nan) |
|
Pwa |
Nport 5610-8: 2,290 g (5.05 lb) Nport 5610-8-48 V: 3,160 g (6.97 lb) Nport 5610-16: 2,490 g (5.49 lb) Nport 5610-16-48 V: 3,260 g (7.19 liv) Nport 5630-8: 2,510 g (5.53 liv) Nport 5630-16: 2,560 g (5.64 lb) Nport 5650-8/5650-8- T: 2,310 g (5.09 lb) Nport 5650-8- M-SC: 2,380 g (5.25 lb) Nport 5650-8- s-sc/5650-16- M-sc: 2,440 g (5.38 liv) Nport 5650-8- HV-T: 3,720 g (8.20 lb) Nport 5650-16/5650-16- T: 2,510g (5.53 lb) Nport 5650-16- S-SC: 2,500 g (5.51 lb) Nport 5650-16- HV-T: 3,820 g (8.42 lb) |
|
Entèfas entèaktif |
LCD panèl ekspozisyon (estanda temp. Modèl sèlman) Pouse bouton pou konfigirasyon (estanda temp. Modèl sèlman) |
Limit anviwònman an
|
Tanperati opere |
Modèl estanda: 0 a 60 degre (32 a 140 degre f) Lajè temp. Modèl: -40 a 75 degre (-40 a 167 degre f) High-vòltaj lajè tanperati. Modèl: -40 a 85 degre (-40 a 185 degre f) |
|
Tanperati depo (pake enkli) |
Modèl estanda: -20 a 70 degre (-4 a 158 degre f) Lajè temp. Modèl: -40 a 75 degre (-40 a 167 degre f) High-vòltaj lajè tanperati. Modèl: -40 a 85 degre (-40 a 185 degre f) |
|
Anbyen imidite relatif |
5 a 95% (ki pa kondansasyon) |
Moxa nport 5630-16 modèl ki disponib
|
Non modèl |
Connector koòdone Ethernet |
Entèfas seri |
No nan pò seri |
Tanp opere. |
Antre vòltaj |
|
Nport 5610-8 |
8- PIN RJ45 |
Rs -232 |
8 |
0 a 60 degre |
100-240 VAC |
|
Nport 5610-8-48 V |
8- PIN RJ45 |
Rs -232 |
8 |
0 a 60 degre |
± 48VDC |
|
Nport 5630-8 |
8- PIN RJ45 |
Rs -422/485 |
8 |
0 a 60 degre |
100-240 VAC |
|
Nport 5610-16 |
8- PIN RJ45 |
Rs -232 |
16 |
0 a 60 degre |
100-240 VAC |
|
Nport 5610-16-48 V |
8- PIN RJ45 |
Rs -232 |
16 |
0 a 60 degre |
± 48VDC |
|
Nport 5630-16 |
8- PIN RJ45 |
Rs -422/485 |
16 |
0 a 60 degre |
100-240 VAC |
|
Nport 5650-8 |
8- PIN RJ45 |
Rs -232/422/485 |
8 |
0 a 60 degre |
100-240 VAC |
|
Nport 5650-8- m-sc |
Multi-mòd Fib SC |
Rs -232/422/485 |
8 |
0 a 60 degre |
100-240 VAC |
|
Nport 5650-8- s-sc |
Single-Mode Fib SC |
Rs -232/422/485 |
8 |
0 a 60 degre |
100-240 VAC |
|
Nport 5650-8- t |
8- PIN RJ45 |
Rs -232/422/485 |
8 |
-40 a 75 degre |
100-240 VAC |
|
Nport 5650-8- hv-t |
8- PIN RJ45 |
Rs -232/422/485 |
8 |
-40 a 85 degre |
88-300 VDC |
|
Nport 5650-16 |
8- PIN RJ45 |
Rs -232/422/485 |
16 |
0 a 60 degre |
100-240 VAC |
|
Nport 5650-16- m-sc |
Multi-mòd Fib SC |
Rs -232/422/485 |
16 |
0 a 60 degre |
100-240 VAC |
|
Nport 5650-16- s-sc |
Single-Mode Fib SC |
Rs -232/422/485 |
16 |
0 a 60 degre |
100-240 VAC |
|
Nport 5650-16- t |
8- PIN RJ45 |
Rs -232/422/485 |
16 |
-40 a 75 degre |
100-240 VAC |
|
Nport 5650-16- hv-t |
8- PIN RJ45 |
Rs -232/422/485 |
16 |
-40 a 85 degre |
88-300 VDC |
